Plotting polar coordinates in Desmos and a vector addition demonstrator
In an earlier post I noted that Desmos did not directly plot polar coordinates. Not only was I incorrect, but Desmos responded to my blog to correct me! Although I had at some point seen that one could define a function f(x)=3x+5 and then have Desmos calculate f(6), I had not absorbed how this might be used to plot polar coordinates. The above works beautifully . Realizing that I could effectively program Desmos, I applied this thinking to demonstrating how to add two vectors when given the magnitudes m and the direction angles theta. The graph calculates the i and j components for the two vectors and then adds the vectors, graphically displaying the result while also providing information on the magnitude and direction of the vector sum. m1 and theta1 are the magnitude and direction angle for one of the two vectors, m2 and theta2 are the magnitude and direction for the other vector. All four are dynamically interactive and can be changed. The diagram purports to illustra
